😊 Many customers ask us during renovation:
“Boss, how much space should I leave for the curtain box?”
Actually, before building the curtain box, just answer these 3 simple questionsand you’ll already have a good idea of how much space you need. 👇
① What curtain style do you want?
👉 Korean Pleat?
👉 S Fold / Wave Fold?
✅ Korean Pleat — more space-saving
✅ S Fold — larger waves, needs more depth
✅ S Fold — gives a more elegant, hotel-style look
② Do you want one layer or two layers?
👉 One layer curtain
👉 Curtain + sheer
One layer is simpler and more economical.
With two layers, you can:
☀️ Close the sheer during the day
🌙 Close the blackout curtain at night
Better privacy + better light control.
③ Do you want motorized curtains?
For one layer:
👉 Manual
👉 Motorized
For two layers:
👉 One motorized + one manual
👉 Both motorized
⚡️ Motorized tracks need more space because you need to allow room for the motor and track system.
So the curtain box usually needs to be deeper.
📏 Recommended Curtain Box Sizes
|
Configuration |
Recommended |
Minimum |
|
1 Layer Korean Pleat – Aluminium Track |
6–7” |
4” |
|
1 Layer S Fold |
7–8” |
5” |
|
1 Layer Motorized Korean Pleat |
7–8” |
5” |
|
1 Layer Motorized S Fold |
8–10” |
5” |
|
2 Layers Korean Pleat |
10–12” |
6” |
|
2 Layers Motorized Korean Pleat |
12–14” |
6” |
|
1 Motorized Korean + 1 Manual Korean |
10–12” |
6” |
|
1 Motorized S Fold + 1 Manual Korean |
12–14” |
8” |
|
2 Layers S Fold |
12–14” |
8” |
|
2 Layers Motorized S Fold |
14–16” |
10” |
📌 Easy way to remember:
✅ Korean Pleat = less space
✅ S Fold = more space for the waves
✅ Motorized track = extra space for the motor
✅ Two layers = deeper curtain box
If the curtain box is too small, you may end up with:
❌ Curtain rubbing or getting stuck
❌ Poor-looking folds
❌ S Fold waves getting compressed
❌ Not enough space for the motorized track
❌ No room to add a sheer curtain later
And of course, the final measurement also depends on:
✔️ Distance between wall and glass
✔️ Air-conditioning concealed trunking
✔️ Lighting design
✔️ Fabric thickness
✔️ Motor model
✔️ Whether Memory Fold / High Temperature Setting is used
So I always tell my customers:
**Curtains can be installed later.
But a curtain box is not so easy to enlarge later!** 😅
Before starting your renovation, talk to your curtain specialist first.
A few minutes of planning can save you from a lot of trouble — and extra renovation costs later. 😊
📲 Mr. Liew WhatsApp: +6012-720 1500
佳美窗帘 | Plus Beauty Curtain Shop
We Have Everything‼️ We Go Everywhere‼️
Plus Beauty Curtain Shop – Since 1993
😊 很多顾客装修时都会问：
老板，窗帘盒到底要留多少？
其实，在做窗帘盒之前，先回答这三个问题，就知道要留多少位置了。👇
━━━━━━━━━━
第一个问题：
您要做什么款式？
👉 韩折？
👉 S Fold？
✅ 韩折比较省空间
✅ S Fold 波浪比较大，需要更多空间
✅ S Fold 的酒店感会比较强
━━━━━━━━━━
第二个问题：
您要做一层还是两层？
👉 一层布
👉 一层布＋一层纱
一层窗帘比较简单、经济。
两层窗帘白天可以拉纱，
晚上再拉布，
隐私和遮光效果都会更好。
━━━━━━━━━━
第三个问题：
要做电动吗？
如果是一层：
👉 手拉
👉 电动
如果是两层：
👉 一层电动＋一层手拉
👉 两层都电动
电动轨道会占用更多空间，
因此窗帘盒也必须预留更大尺寸。
━━━━━━━━━━
三个问题回答完后，
窗帘盒尺寸基本就出来了。
装修前先决定：
① 做什么款式？
② 做几层？
③ 要不要电动？
这样木工、石膏天花和窗帘师傅才能一次做到位。😊
这里帮大家整理成最简单、最实用的版本👇
配置 建议尺寸 最少尺寸
一层韩折（铝轨） 6～7寸 4寸
一层 S Fold 7～8寸 5寸
一层电动韩折 7～8寸 5寸
一层电动 S Fold 8～10寸 5寸
两层韩折 10～12寸 6寸
两层电动韩折 12～14寸 6寸
一层电动韩折＋一层韩折（铝轨） 10～12寸 6寸
一层电动 S Fold＋一层韩折（铝轨） 12～14寸 8寸
两层 S Fold 12～14寸 8寸
两层电动 S Fold 14～16寸 10寸
📌 简单记：
✅ 韩折比较省空间
✅ S Fold 需要更大的波浪空间
✅ 电动轨需要预留电机位置
✅ 两层窗帘需要更深的窗帘盒
如果窗帘盒留太小，很容易出现：
❌ 窗帘卡住
❌ 布浪不漂亮
❌ S Fold 被压扁
❌ 电动轨无法安装
❌ 以后想加纱没位置
当然，最终尺寸还需要考虑：
✔️ 墙壁和玻璃之间的距离
✔️ 是否有冷气暗槽
✔️ 是否有灯槽设计
✔️ 布料厚度
✔️ 电机型号
✔️ 是否做高温定型
所以我常常跟顾客说：
窗帘可以后做，窗帘盒不能后补。
装修前先问窗帘师傅，
永远比装修后才发现位置不够来得更省钱。😊
